ProLiant DL360 Gen9 (G9) LRDIMM

System Information

Manufacturer Specifications:

Memory Sockets: 24 slot(s)
Maximum Memory: Supports up to 1.5TB
Model Id: 755260-B21, 755261-B21, 755262-B21, 755263-B21, 795236-B21

Product Notes:

Supports up to 2 Intel Xeon E5-26xx v3 processor. Each processor can access 12 DIMM memory slots (4 channels per processor, 3 DIMMs per channel). DDR4 Registered (RDIMM) or Load Reduced (LRDIMM) supported but cannot be mixed. Maximum LRDIMM capacity 1.5TB (24x64GB). Maximum RDIMM capacity 768GB (24x32GB). While 2133MHz DIMMs will work with any E5-26xx v3 processor, speed may be reduced to 1866MHz or 1600Mhz depending on processor model. E5-269x v3, E5-268x v3, E5-267x v3, E5-266x v3, E5-265x v3, E5-2643 v3 and E5-2637 v3 processors support 2133MHz DIMMs. E5-264x v3 (not E5-2643 v3), E5-263x v3 (not E5-2637 v3) and E5-262x v3 processors support 1866MHz DIMMs E5-260x v3 processors support 1600MHz DIMMs. When 1 processor is installed, install DIMMs in sequential alphabetic order: A, B, C, D, E, F...etc. When 2 processors are installed, install DIMMs in sequential alphabetic order: CPU1-A, CPU2-A, CPU1-B, CPU2-B, CPU1-C, CPU2-C etc. Pre-Configured model SKUs: 755260-B21 come with 1x8GB 2133MHz RDIMM (8GB) and 1 processor. 755261-B21 come with 1x8GB 2133MHz RDIMM (8GB) and 1 processor. 755262-B21 come with 1x16GB 2133MHz RDIMM (16GB) and 1 processor. 755263-B21 come with 2x16GB 2133MHz RDIMM (32GB) and 2 processors. 795236-B21 come with 2x16GB 2133MHz RDIMM (32GB) and 2 processors.
